It can realize the splicing of glasses acetate nose pad cutting or end_piece
cutting,and realize the direct splicing without spliching water and other
accessories.It has fast speed,low noise,strong stability and good fusion
splicing.The splicing surface is even.
360-degree friction machine head
Japan imported electrical appliances
Imported infrared inductor
Taiwan cylinder
Imported motor
Discharging mechanism
Material clamping mechanism
It can save time and labor, and realize the direct splicing without splicing water.
The adjustment is convenient, and the cutting is fast.
Environmentally-friendly and clean.
Performance index | standard value |
Working voltage | 380V/Three-phase |
Operating system | PLC man-machine interface |
Machine power | 3KW |
Working noise | 70DB |
Operating frequency | 600HZ |
Air pressure | 0.6MPA |
Machine tool weight(KG) | 500KG |
Machine dimension | 800*800*1650mm |
Production speed | Three deputies/minute |
